Hydraulic Hose Cutting Machine SNP-C20
Hydraulic Hose Cutting Machine SNP-C20
Short Description:

Products Name: Hose Cutting Machine
Cutting range: 1/4”-2” 4S & 3” 2S
Motor Power: 5.5Kw
Standard voltage :380V/50Hz
Diameter L*W*H:810mm*610mm*1150mm


  • :
  • :
    • HYDRAULIC HOSE 1SN-7-factory-1

      Brief Introduction



      Sinopulse hose cutting machine are highest precision and efficiency to cutting the hydraulic hose range from 3/18” to 3” in the world wide.

      This model cutting machine have solid and compact tools keeps the cutting function sage and high quality level.

      With the powerful motors and property positioning and extraordinarily sharp cutting blades is the biggest advantage of our machine

      Less vibration makes the machine durability and low maintenance expense.

      The users like the no scales and extraordinarily small smoke when they manufacture the hydraulic hose assemblies.

      CE standard brake motors insure the machines are low energy consumption, high economic deficiency, particular in bulk production lines.



      The oversized shafts avoid vibration and extend service life of maximizing blade and motor. It is also suitable for the faster and straighter cutting process.

      The brake motor and operating guarding helps us meet the safety regulations.

      Hose cutting machine C20-1

      Product Parameter


      Part No. : C20
      Cutting Range:  2"  4S & 3" 2S
      Max ¤ 100m
      Revolutions/minute:  2900r/min
      Pneumatic input  0.8Mpa
      Blade Measure  350mm
      Dimension LxWxH 810mm*610mm*1150mm
      Standard voltage : 380V/50Hz
      Motor power : 5.5kW
      Measuring Hose Holder Optional

      Feature Description



      1.Simple structure, economical and applicable
      2.Adjustable handle working stroke amplitude
      3.Foot pedal control
      4.Safety operation and high efficient
      5.Adopted the dust-extraction unit
      6.Low noise

      Application



      This model is suitable for cutting all kinds of steel wire braided hose1SN, 2SN R1,R2, R5, R4, R16, R17, 1SC, 2SC, steel wire spiraled hose R12, R13, R15, 4SP, 4SH, adding cloth hose and cotton reinforced hose range from 6mm to 51 mm (1/4”-2” ).
      It is the best choice for making hose assemblies maintenance and manufacturers
