Name: AIR-WATER hose 20 bar/300psi
Availability: InStock
Rating: 4.5 (89 reviews)

AIR-WATER hose 20 bar/300psi

Short Description:

Construction:
Surface: Smooth surface and textile surface
Tube: NR & SBR synthetic rubber, black color.
Reinforcement:1ply or 2ply high tensile polyester thread braiding, multiple ply high tensile fabric
Cover: NR & SBR synthetic rubber,smooth or wrapped surface, black,yellow,red available
Working pressure: 10 BAR/ 20 BAR
BURST pressure: 30 BAR/ 60 BAR
Safety: 3:1
Temperature: -20℃(-4℉)to 80℃(+176℉)

download Contact Us Now >

Description
Product Tags

Product Description

SINOPULSE FACTORY offers a variety of Industrial, Air – Water, and Multipurpose Hose to handle any application. Our hoses are designed to perform in both high and low and pressures and are suitable for a variety of applications.

Product Parameter

Part No.	ID		OD	Working Pressure		Burst Pressure		Length
Part No.	inch	mm	mm	Bar	psi	Bar	psi	M
AS300-04	1/4"	6.4	13	20	300	60	900	100
AS300-05	5/16"	7.9	15	20	300	60	900	100
AS300-06	3/8"	9.5	17	20	300	60	900	100
AS300-08	1/2"	12.7	21	20	300	60	900	100
AS300-10	5/8“	15.9	24.5	20	300	60	900	100
AS300-12	3/4"	19.1	29	20	300	60	900	100
AS300-16	1"	25.4	35	20	300	60	900	100

Part No.	ID		OD	Working Pressure		Burst Pressure		Length
Part No.	inch	mm	mm	Bar	psi	Bar	psi	M
AW300-04	1/4"	6.4	15	20	300	60	900	100
AW300-05	5/16"	7.9	17	20	300	60	900	100
AW300-06	3/8"	9.5	19	20	300	60	900	100
AW300-08	1/2"	12.7	22	20	300	60	900	100
AW300-10	5/8“	15.9	26	20	300	60	900	100
AW300-12	3/4"	19.1	30	20	300	60	900	100
AW300-16	1"	25.4	36	20	300	60	900	100
AW300-20	1.1/4"	31.8	44	20	300	60	900	100
AW300-24	1.1/2"	38.1	52	20	300	60	900	100
AW300-32	2"	66	66	20	300	60	900	100

Characteristics:

Anti-aging synthetic rubber
Weather and ozone resistant
Excellent abrasion resistance

Quality Control:

No recycle material
abrasion resistance
Pressure test
Tensile strength
Monitoring vulcanization

Application

Mainly used for convey of air, insert gas and water in mining, construction, engineering, shipbuilding , steel production etc.

Product Advantage

Why Choose Us?
1.15 years experience and ISO 2015 Certificated manufacturer
2. Laboratory test give us TOP quality raw material
3. Responsibility card supervise every step during production
4. Strict Quality control institution after production
5. Fast,Friendly,knowledgeable sales & sales professional with extended business hours service
6.After-sale service guarantee & warranty
7. OEM brand service is available.

We strive to be the best fluid and power convey company in the world to make our products not only outperform industry standards, but also exceed our customers’ demanding expectations.

Whether you’re in construction, agriculture, mining, petroleum processing, foundry, shipyard, or quarry you can count on SINOPULSE FACTORY for all your needs.

We welcome to all new and clients customers get in touch with us for future small business interactions and mutual success. The products will supply to all over the world, such as Italy, Germany,UK,Spain.USA,Canada,Brazil,Argentina,Panama,Peru,Chile,Vietnam,Indonesia, Australia…..we are confident that we are going to possess a vibrant prospect and to be distributed all over the world in the near future.
